home page > CLASSIFICATION > Classification List > product details
74LVC2G53GS,115
74LVC2G53 - 2-CHANNEL ANALOG MUL
part Number：
74LVC2G53GS,115
Alternative models：
74LVC2G53GT,115,74LVC1G3157FZ4-7,TC7USB42MU,LF(S2E,ST4-50-1.00-L-D-P-TR,TPS61236PRWLR,NSP4201MR6T1G,74LVC1G3157DW-7,FXMA2102L8X
manufacturer：
NXP
category：
Integrated Circuits (ICs) > Interface > Analog Switches, Multiplexers, Demultiplexers >
describe：
74LVC2G53 - 2-CHANNEL ANALOG MUL
RoHS：
NO
：
74LVC2G53GS,115
74LVC2G53GS,115 specifications
Mounting Type：
Surface Mount
Number of Circuits：
1
Operating Temperature：
-40°C ~ 125°C (TA)
Package / Case：
8-XFDFN
Switch Circuit：
SPDT
Multiplexer/Demultiplexer Circuit：
2:1
On-State Resistance (Max)：
10Ohm
Voltage - Supply, Single (V+)：
1.65V ~ 5.5V
-3db Bandwidth：
300MHz
Channel Capacitance (CS(off), CD(off))：
6pF
Charge Injection：
7.5pC
Current - Leakage (IS(off)) (Max)：
5µA
Supplier Device Package：
8-XSON (1.35x1)
Switch Time (Ton, Toff) (Max)：
3.8ns, 3.8ns
