PESD5V0F1BRLDYL
TVS DIODE 5.5VWM 15VC DFN1006D-2
part Number：
PESD5V0F1BRLDYL
Alternative models：
PESD5V0F1BLD,315,B340AQ-13-F,PESD5V0F1BRLDYL,PESD5V0F1BL,315,TPSMD18CA
manufacturer：
NXP
category：
Circuit Protection > Transient Voltage Suppressors (TVS) > TVS Diodes >
describe：
TVS DIODE 5.5VWM 15VC DFN1006D-2
RoHS：
NO
：
PESD5V0F1BRLDYL
PESD5V0F1BRLDYL specifications
Grade：
Automotive
Operating Temperature：
-40°C ~ 125°C (TA)
Mounting Type：
Surface Mount, Wettable Flank
Qualification：
AEC-Q101
Package / Case：
2-XDFN
Supplier Device Package：
DFN1006D-2
Applications：
Ethernet
Type：
Zener
Power Line Protection：
No
Bidirectional Channels：
1
Voltage - Breakdown (Min)：
6V
Voltage - Clamping (Max) @ Ipp：
15V
Capacitance @ Frequency：
0.4pF @ 1MHz
Voltage - Reverse Standoff (Typ)：
5.5V (Max)
Current - Peak Pulse (10/1000µs)：
2.5A (8/20µs)
